BAU Prestige

Window system Prestige

Superbly balanced Harmonised design combined with a high level of functionality such as excellent sound insulation and very good thermal insulation values fully satisfy the latest requirements of the Energy Saving Regulation and the values required for entitlement to KfW financial support (German Reconstruction Loan Corporation). Using the state-of-the-art 6-chamber technology and a profile depth of 76 mm you can benefit from great energy savings and substantially reduce heating costs. This quality product is available with the same high-quality internal workings in the four different design variants and a wide range of colours, and also with aluminium cappings. Matching front doors and lift and sliding doors are also available for the Prestige system.

Technical Specifications

• 76 mm system, 6 chambers
• Insulation value of entire window Uw up to 0.66 W/m2K
• 4 different sash designs available
• Accommodates glazing thickness of up to 44 mm for thermal and acoustic insulation and up to 56 mm with the new system Prestige classic, semi-offset
• Also with Thermo Profile made from recycled material for enhanced thermal insulation
• Frame insulation value: Uf = 1.0 W/m2K with thermal reinforcement; Uf = 1.1 W/m2K with centre seal; Uf = 1.2 W/m2K with rebate seal
• Curves and 20° bevels ensure a good water run-off and harmonic design
• Inner 2-foot glass bead for enhanced burglary protection
• Glass rebate height of 25 mm for avoidance of condensation water
• Three framed weldable TPE seals with centre sealing system, two with rebate seal system
• RAL-certified overlap bonding for floor-to-ceiling elements of up to 2.60 m
• Use of adhesive tape for dry adhesion with the new multifunctional sash
• Soundproofing up to 47 dB (noise protection class 5)
• 40 different laminated foil colours
• Prestige classic offset, also available with aluminium cladding – unlimited choice of colours

Color Options
